APPENDICES
APPENDIX D - M2000 SPECIFICATIONS
INDICATOR PERFORMANCE
UNIT CONVERSION lbs / kg
ZERO TRACKING 1-99% of d or 1,2,3d
RESOLUTION (M2000A) +/- 520,000 A/D counts per loadcell
RESOLUTION (M2000D) +/- 256,000 A/D counts per loadcell
SAMPLING RATE 100 times per second per AD channel
SPAN STABILITY 2ppm/ Celsius
ZERO STABILITY 5nV/Celsius
LINEARITY CORRECTION 5 span entries
CALIBRATION METHOD Calibration through software stored in Flash memory
CALIBRATION SEALING Class 1 Audit Trail System, password protected
FILTERING FASTSTEP quick response
MODES Display from CH1, CH2, CH3 and TOTAL MODE (All Channels)
FIRMWARE UPGRADING
Flash Memory - In field Firmware upgrading without affecting
calibration data.
LOAD CELLS Analog Cells. M2000D: Up to 16 Loadcells using two DLC slaves
LOADCELL INPUTS
FULL SCALE 4 ranges: 0-9mV, 0-19mV, 0-39mV, and 0-79mV
EXCITATION (M2000D) 5VDC,16x350, 32x700 ohm in total
EXCITATION (M2000A) 7.5VDC,16x350, 32x700 ohm in total
COMMUNICATIONS
SERIAL OUTPUTS 2 full duplex RS232/RS422 (1 only with Single Channel model)
IO INTERFACE SMART WIRE peripheral expansion: RS485 multi-drop
EXTERNAL IO:
SETPOINTS
6 channel Setpoint via SMARTWIRE (optional)
EXTERNAL IO:
ANALOG OUTPUT
4-20mA board via SMARTWIRE (optional)
EXTERNAL IO:
DIGITAL INPUTS
6 optically isolated inputs via SMARTWIRE (optional)
NETWORKING RS485 Multi-drop Networking of up to 32 indicators as slaves
ELECTRICAL
POWER REQUIREMENTS 12VDC, 1 Amp. (1.5A maximum)
POWER DRAW 200 mA
TEMPERATURE RANGE -10C to +40C
RFI PROTECTION Filtered Signal, Excitation, & Sense lines
ENCLOSURES
STAINLESS
Wash-down stainless steel enclosures. Panel mount, swivel-bracket, or
desktop. Light Stainless or NEMA 4-X.
ALUMINIUM Slimline. M2000A only. 12 GA. Cast aluminium.
APPROVALS
MEASUREMENT CANADA AM 5371 – Rev.1
NTEP 00-076A1
CSA CSA Approved Power Supply
OIML Pending
