TECHNICAL MANUAL
POWER SWITCH ([ON/OFF] KEY) BYPASS - PARAMETER 10
Description: Allows the [ON/OFF] key to be disabled.
PARAMETER VALUE ACTION
0
Disables the [ON/OFF] key. The M2000 cannot be
turned off from the keypad. The M2000 will power on
when plugged in without pressing the [ON/OFF] key.
1 (default) Enables the [ON/OFF] key.
LOADCELL VOLTAGE RANGE - PARAMETER 11
Description: Adjusts the Loadcell Voltage Range. This parameter
accounts for loadcells with reversed polarity as shown by the
“+/-“.
It is important that the correct range be selected for optimal
performance of the indicator.
PARAMETER VALUE LOADCELL VOLTAGE RANGE
1 (default) 0 to +/- 9mV
2 0 to +/- 19mV
3 0 to +/- 39mV
4 0 to +/- 79mV
Note: This parameter is used in applications such as control
systems where the M2000 must power up running after a power
outa
g
e.
Selecting a lower voltage range does not guarantee better
performance! Lower ranges have more amplification so as A/D
counts rise, line noise may be amplified depending on the scale
installation.
Note: If the loadcell input voltage exceeds the input range of the
indicator the display will display ‘AAAAAA’ for “Analog over-range”.
Select the next highest input range to rectify the problem.
