33
TECHNICAL MANUAL
13P
C4276
5
C5000
0
5000P
C 0
0
SET SPAN - PARAMETER 13
Description: Calibrates (Spans) the scale with a known Test Weight.
EXAMPLE: IN CALIBRATION MODE, SPAN A SCALE TO 5,000 LBS.
1. Verify that scale is reading zero with the Centre of Zero LED
illuminated.
2. Place Test Weights on the scale (5,000 lbs).
3. Enter 13 followed by the [PRINT/SELECT] key. Once
activated, the current displayed weight will be frozen on the
display.
4. Enter the known test weight value followed by the
[PRINT/SELECT] key. The display will show the new, corrected
weight on the scale.
IMPORTANT NOTICE FOR HIGH CAPACITY SCALES & SCALES
UTILIZING A LARGE NUMBER OF LOADCELLS!
PLEASE VERIFY THAT THE CORRECT ANALOG INPUT RANGE
IS SET BEFORE PROCEEDING TO SPAN SCALE. (SEE
PARAMETER 11 - PAGE 47)
