SCALE MOTION PARAMETERS
The following parameters are used for adjusting MOTION characteristics.
These settings are useful for installations experiencing instability problems, and
adjusting the performance of the Motion character in the Output string.
MOTION WINDOW MULTIPLIER - PARAMETER 5
Description: Determines the scale’s sensitivity to motion.
This Parameter Value is multiplied by the Graduation Size to give
the Motion Window. A change in weight must be greater than this
window to activate the MOTION LED.
To decrease Motion Sensitivity, increase the value of this
parameter.
Default Value: 2 - When Graduation Size (Parameter 3) is set, the Motion
Window is automatically set to 2 times the Graduation size.
Accepted Values: 1 – 10
EXAMPLE: AN OLD AND UNSTABLE SCALE. THE WEIGHT IS NOT
SETTLING FAST ENOUGH. DECREASE MOTION SENSITIVITY.
1. In Calibration Mode, press 5, followed by the [PRINT/SELECT] key to
select “Motion Window.” A “2” will be displayed (Default value).
2. Press 4 followed by the [PRINT/SELECT] key to double the value.
3. The motion sensitivity will now be 4 times the graduation size. If the Grad
Size is 10 kg, MOTION will not be indicated (blinking LED) unless the
weight on the scale changes by more than 40 kg (4 x 10 kg).
BE SURE TO REFERENCE LOCAL REGULATORY
REQUIREMENTS.
