Western Scale M2000 - Example: Assigning Setpoints

HIGH SPEED DIGITAL WEIGHT INDICATORS
90
c 0
19P
------
57P
0000
0000
000011
11P
----11
EXAMPLE: ASSIGN SETPOINTS 1 & 2 TO ENERGIZE OUTPUT WHEN THE
WEIGHT ON CHANNEL 1 IS LESS THAN THE SETPOINT VALUE.
1. Enter Calibration Mode for Scale Channel 1.
2. Enter the Setpoint Control Mask (Parameter 57). When Parameter 57 is
entered for the first time, dashes will be shown across the display.
3. Press [0] four times to skip Setpoints 6, 5, 4, and 3.
4. See the Setpoint Function table. Press [1] twice.
5. Enter Parameter 57 again to check the value. Note the Setpoint mask.
Setpoints 1 and 2 have now been assigned the “>=” function. Now assign
Setpoint 6 the “<” function.
1. Enter Parameter 57 followed by the [PRINT/SELECT] key.
2. Then enter “200000” followed by the [PRINT/SELECT] key.
3. If Parameter 57 is entered, the Setpoint Mask shows “2---11”.
Disable Setpoint 6.
1. Enter Parameter 57 followed by the [PRINT/SELECT] key.
2. Then enter “300000” followed by the [PRINT/SELECT] key.
3. If Parameter 57 is entered, the Setpoint Mask shows “----11”.
To exit or abort, press the [CLEAR] key at any time.
