Western Scale M2000 - Appendix D - M2000 Specifications

103
APPENDICES
DF2000 STRING
<STX><POL><SP><WWWWWW><SP><Units><Channel Info><Mode><SP><Status><CR><LF>
POSITION CHARACTER CHARACTER VALUES
1 STX
Start of Text Character (ASCII 02)
2 Polarity
“-“ for Negative , Space for Positive
3 Space
ASCII 32
4 W
5 W
6 W
7 W
8 W
9 W
Weight String (Padded with spaces)
Least Significant Digit
10 Space
ASCII 32
11 Units
12 Units
“KG” = Kilograms
“LB” = Pounds
13 Channel Info
* See Command Mode table below:
14 Mode
15 Mode
“GR” = Gross weight
“NT” = Net weight
16 Space
ASCII 32
17 Status Space=Valid, “O”=Over, “M”=Motion, “-“=Negative
18 CR
Carriage Return (ASCII 13)
19 LF
Line Feed (ASCII 10)
