Western Scale M2000 - Consolidated Controls String; Weightronix 120 String

HIGH SPEED DIGITAL WEIGHT INDICATORS
108
CONSOLODATED CONTROLS
<STX><POL><WWWWWWW><Units><Mode><Status><SP><CR><LF>
POSITION CHARACTER CHARACTER VALUES
1 STX
Start of Text Character (ASCII 02)
2 Polarity
“-“ for Negative , Space for Positive
3 W
4 W
5 W
6 W
7 W
8 W
9 W
Weight String (Padded with spaces, includes
decimal point)
Least Significant Digit
10 Units
“K” = Kilograms, “L” = Pounds
11 Mode
“G” = Gross weight, “N” = Net weight
12 Status Space=Valid, “O”=Over, “M”=Motion
13 Space
ASCII 32
14 CR Carriage Return (ASCII 13)
15 LF Line Feed (ASCII 10)
WEIGHTRONIX 120 FORMAT
<SP><Mode><POL><WWWWWW><SP><Units><CR><LF>
POSITION CHARACTER CHARACTER VALUES
1 Space
ASCII 32
2 Mode
“G” = Gross weight, “N” = Net weight
3 Polarity
“-“ for Negative , “+” for Positive
4 W
5 W
6 W
7 W
8 W
9 W
Weight String (6 Characters, padded with spaces)
Least Significant Digit
10 Space
ASCII 32
11 Units
12 Units
“KG” = Kilograms
“LB” = Pounds
13 CR
Carriage Return (ASCII 13)
14 LF
Line Feed (ASCII 10)
