TECHNICAL MANUAL
SERIAL HANDSHAKING (RTS / CTS) - PARAMETER 36 & 37
Handshaking for COM1: Parameter 36
Handshaking for COM2: Parameter 37
PARAMETER VALUE SERIAL HANDSHAKING
0 Disabled (factory default)
1 Enabled
STRING OUTPUT MODE - PARAMETER 38 & 39
Description: Determines how the M2000 outputs strings to the COM
ports.
String Output Mode for COM1: Parameter 38
String Output Mode for COM2: Parameter 39
PARAMETER VALUE STRING TRANSMITS TO COM PORT…
1 When the [PRINT/SELECT] key has been pressed.
2
When the COM port receive data input is at logic low (-9
Volts DC).
3
When the COM port receive data input is at logic high (+9
Volts DC).
4 When the ‘?’ character is received.
5 Continuously (factory default).
Remember that the default String Output Modes for COM1 and
COM2 are different.
Parameters 38 and 39 can be ignored if a “Command Mode”
Output String (Eg. DF2500 Command Mode 7) has been selected.
(See Parameters 34 & 35 – Page 33)
