Western Scale M2000 - Motion Settle Time (Example)

39
TECHNICAL MANUAL
24P
8
16P
MOTION SETTLE TIME - PARAMETER 24
Description: Displays the number of ¼ second intervals that Motion will
be indicated after the scale reading has stabilized within
tolerance.
Motion is indicated by:
• A blinking Scale Channel LED.
• The presence of an ASCII character ‘M’ in the Output
String. (For most Output String Formats)
Default Value: 8 (2 seconds)
Accepted Values: 1 - 255
EXAMPLE: THE SCALE COMMUNICATES WITH A CONTROL SYSTEM OR
DATABASE. THE SYSTEM WANTS TO SEE A STABLE
WEIGHT FOR AT LEAST 4 SECONDS BEFORE IT PROCESSES
THE SCALE INFORMATION.
1. Enter 24 followed by the [PRINT/SELECT] key. An ‘8’ will be
displayed (Default value).
2. Sixteen (16) ¼ second intervals are needed for a Motion Settle
Time of 4 seconds (16 x ¼ sec).
