TECHNICAL MANUAL
DATA BITS (COM2 ONLY) - PARAMETER 27
Description: COM1 on the M2000 is fixed at 8 Data Bits. However, if
EVEN or ODD Parity is selected then 7 Data Bits will
automatically be used.
COM2 allows for independent selection of Data Bits.
Parameter 27 is used to set this value.
PARAMETER VALUE DATA BITS
0 COM2 Data Bits set to 4
1 COM2 Data Bits set to 5
2 COM2 Data Bits set to 6
3 COM2 Data Bits set to 7
4 COM2 Data Bits set to 8 (default)
BAUD RATE - PARAMETER 30 & 32
Baud rate for COM1: Parameter 30
Baud rate for COM2: Parameter 32
PARAMETER VALUE BAUD RATE
0 150
1 300
2 600
3 1200
4 2400
5 4800
6 9600 (factory default)
7 14400
8 19200
9 32400
PARITY - PARAMETER 31 & 33
Parity for COM1: Parameter 31
Parity for COM2: Parameter 33
PARAMETER VALUE PARITY
0 No parity (factory default)
1 ODD parity
2 Even parity
