HIGH SPEED DIGITAL WEIGHT INDICATORS
104
CHANNEL INFO CHARACTER:
CHARACTER WEIGHT FROM:
1
Channel 1
2
Channel 2
4
Channel 3
3
Sum of channels 1 and 2
5
Sum of channels 1 and 3
7
Total Mode (Sum of Channels 1,2,3)
DF2000 COMMAND MODE
Simple 1-character command mode. When the indicator receives a command, it
replies with the DF2000 string. The single character commands are listed below.
CHARACTER ACTION
?
Send Current Displayed Weight
1
Set to Channel 1 and send displayed weight
2
Set to Channel 2 and send displayed weight
3
Set to Channel 3 and send displayed weight
4
Set to Total Mode and send displayed weight
T
Set Tare on current channel
C
Clears stored Tare weight
G
Switches to Gross mode
N
Switch to Net mode if a Tare weight is stored
Z
Zeroes indicator if within ZERO window
