HIGH SPEED DIGITAL WEIGHT INDICATORS
16
BATTERY REPLACEMENT ON THE M2000
The M2000 uses a 3 Volt Lithium Battery to run the real-time clock and backup
the indicator’s memory. Power is drawn from the battery only when the indicator
is disconnected from the 12 Volt power supply. So, if the indicator is in regular
use, the battery should have a long lifespan.
TESTING THE BATTERY - PARAMETER 244
Description: Used to take a measurement of the 3 Volt lithium battery. Voltage
levels are in mV and can be interpreted below.
In Calibration Mode, enter Parameter 244.
PARAMETER VALUE SETPOINT FUNCTION
3000 (3.0V) 3 Volts and above is considered good.
2700 (2.7V) 2.7 Volts and above is considered acceptable.
2600 (2.6V)
2.6 Volts or less is considered as low. Replace
battery.
REPLACING THE BATTERY
1. Remove the M2000’s back cover.
2. A coin-sized battery is located in a battery holder. (Upper left corner of the
M2000 PCB).
3. Use your fingers to grab each edge of the battery.
4. Gently pull on an angle removing the battery from the holder.
Replace the battery with a type RENATA CR2450N 3V 540mAh
lithium battery or equivalent. This battery should be available at
most electronics stores.
NEVER USE METAL OBJECTS SUCH AS SCREWDRIVERS TO
REMOVE THE BATTERY. THIS CAN RESULT IN PERSONAL
INJURY AND/OR A SHORT-CIRCUITING OF THE BATTERY
CAUSING DAMAGE TO THE INDICATOR.
