HIGH SPEED DIGITAL WEIGHT INDICATORS
54
USING LINEARITY TABLES TO SET SPAN
Having different Span Values at different weight ranges helps to correct any
structural or loadcell non-linearity. M2000 Indicators allow Technicians to set
spans for up to 4 weight ranges using 4 linearity table entries.
RESET SPAN TABLE - PARAMETER 15
Description: Clears the span table except for the first entry. It is recommended
that this be done before calibrating the M2000.
INCREMENT SPAN TABLE POINTER - PARAMETER 16
Description: To add a calibration entry to the Span Table, the Span Table
Pointer must be incremented. This allows for further Span
adjustments to correct scale linearity errors.
Upon activation, the current Span Table Pointer (1 to 4) will be
displayed. Press [TARE] to increment the Pointer by 1
DECREMENT SPAN TABLE POINTER - PARAMETER 17
Description: Moves the Span Table Pointer back through the Span Table.
Upon activation, the current Span Table Pointer value (1 to 4) will
be displayed. Press [TARE] to decrement the Pointer.
The Pointer cannot decrement past 1.
IF YOU HAVE A NON-LINEARITY ERROR OF MORE THAN 3
GRADUATIONS, A CLOSER MECHANICAL INSPECTION OF THE
SCALE AND ITS INSTALLATION IS REQUIRED.
