HIGH SPEED DIGITAL WEIGHT INDICATORS
50
SCALE FILTERING PARAMETERS
Digital Averaging, or Filtering, applies a certain number of weight samples taken
by the indicator and averages them to display a stable weight in situations where
the scale is subject to vibration or any other movement.
The M2000 has 2 digital filters to provide optimal weight readings on the display
in unstable conditions such as in-motion, on-board, and livestock weighing.
Main Filter: Used to stabilize the scale once a sustained weight is supplied
or the scale is at zero. The M2000 detects that a weight change
is “flattening out” and uses the Main Filter.
Faststep Filter: Used to dramatically improve the display response time for a
significant change in weight. When weight is being applied to
(or removed from) the scale, the M2000 detects that the weight
is changing rapidly and switches to the Fastep Filter, quickly
bringing the M2000 display to the target weight.
Without the Faststep Filter, the scale would be much slower in reaching the final
weight reading and returning to zero.
FASTSTEP DIAGRAM:
SCALE HAS A
STABLE LOAD
AT ZERO.
(MAIN FILTER)
M2000 DETECTS
WEIGHT IS
FLATTENING
OUT.
SWITCHES TO
MAIN FILTER
SCALE IS BEING
LOADED. M2000
SWITCHES TO
FASTSTEP TO GET
WEIGHT CLOSE TO
TARGET QUICKLY.
M2000 DETECTS
APPROACHING ZERO,
SWITCHES TO MAIN
FILTER TO STABLIZE
ZERO
A SLIGHTLY
SHIFTING LOAD IS
STABLIZED BY
MAIN FILTER.
WEIGHT IS BEING
REMOVED. M2000
SWITCHES TO
FASTSTEP TO GET
WEIGHT CLOSE TO
ZERO QUICKLY.
The default Filtering Settings should be appropriate for most
applications.
