HIGH SPEED DIGITAL WEIGHT INDICATORS
110
ANALOGIC 5316
<STX><WWWWWWWWW><TTTTTTTTT><SP><Status><Units><SP><CR><LF>
POSITION CHARACTER CHARACTER VALUES
1 STX
Start of Text Character (ASCII 02)
2 W
3 W
4 W
5 W
6 W
7 W
8 W
9 W
10 W
Weight String (Padded with spaces, includes
decimal point and SIGN character)
Least Significant Digit
11 T
12 T
13 T
14 T
15 T
16 T
17 T
18 T
19 T
TARE Weight String (Padded with spaces,
includes decimal point and SIGN character)
Least Significant Digit
20 Space
ASCII 32
21 Status
“1”= In Range, “2”= Standstill, “4”= Center of Zero,
“8”= Net Mode (Bit Masking)
22 Units
“0”= Kilograms, “1”= Pounds
23 Space
ASCII 32
24 CR
Carriage Return (ASCII 13)
25 LF
Line Feed (ASCII 10)
