HIGH SPEED DIGITAL WEIGHT INDICATORS
60
SERIAL COMMUNICATIONS SET-UP PARAMETERS
The M2000 has 2 fully independent, fully configurable serial ports (COM1 and
COM2) on the back of the indicator. The factory default settings allocate COM1
for printing tickets. COM2 is allocated for outputting a weight string (DF1500) in
continuous mode. RS232 & RS422 are available.
M2000 SERIAL WIRING CONNECTIONS
• A serial cable is required to connect the M2000 to a PC, Printer, data
controller, or other serial device. Connections are as follows:
M2000 9 PIN SERIAL PORT 25 PIN SERIAL PORT
CTS PIN 8 PIN 5
RX PIN 2 PIN 3
TX PIN 3 PIN 2
RTS PIN 7 PIN 4
COM PIN 5 PIN 7
DEFAULT SETTINGS
COM 1 DEFAULT SETTINGS
COM 2 DEFAULT SETTINGS
Baud Rate 9600 9600
Parity None None
Data Bits 8 (fixed) 8
Stop Bits 1 1
String Output [PRINT/SELECT] KEY Continuous
Flow Control None None
Output Mode Press [PRINT/SELECT] Continuous
Driver RS 232 RS 232
Please note that Single Channel Models only have one serial port
(COM1).
Parameters and Parameter Values pertaining to COM2 are not
supported on single channel indicators.
