M2000 POWER UP
• On power up, M2000 Indicators should display a scrolling “M2000”
followed by the software version number.
• If the scale system has been installed correctly, a weight should then
be displayed.
TROUBLE SHOOTING
IF THE M2000 DOES NOT POWER UP:
• Check External power source and Circuit Breaker.
• Check 12V Power Supply and replace if necessary.
IF THE ALPHA-NUMERIC DISPLAY SHOWS:
• There is no Signal Input. The loadcell cable to the M2000
may have been disconnected, wired incorrectly, or
severed. The loadcell could be defective.
• Sense lines from the loadcell have not been terminated.
Connect Sense wires or jumper +EXC to +SNS and
–EXC to –SNS.
• The loadcell’s output is beyond the M2000’s Input
Voltage Range. (See Parameter 11 - Page 47 to adjust
this range)
• The scale is overloaded at the M2000’s default settings.
Remove any weights that may be on the scale and
Deadload the scale. (See Parameter 12 – Page 32)
