HIGH SPEED DIGITAL WEIGHT INDICATORS
62
OUTPUT STRING FORMAT - PARAMETER 34 & 35
Description: Several different indicator string formats can be emulated by the
M2000. To create a custom transmit string for a ticket, the COM
Port must be set to 99.
String Format for COM1: Parameter 34
String Format for COM2: Parameter 35
PARAMETER VALUE OUTPUT STRING
1 DF1000
3 DF2000 (DF2000 Command Mode)
5 DF2500 mode1
8 DF1500 (factory default Com2))
9 DF2500 Command Mode 6
10 DF2500 Command Mode 7
12 AD4321, AD4323, AD5000
13 Cardinal 708
14 Cardinal 738
16 Weightronix 120
17 Consolidated Controls UMC600
18 Analogic 5316
19 Toledo & Fairbanks R2500
99
Custom Transmit/Ticket Printer Mode (default Com1)
100
Bar Code Scanner Mode (See Page 74)
For more information on creating a custom ticket and other M2000
ticket options, please refer to the M2000 Ticket Options Manual.
For a complete breakdown of M2000 emulated string formats,
please see Appendix C.
