HIGH SPEED DIGITAL WEIGHT INDICATORS
28
Note: To enter Calibration Mode for Channels 2 & 3, use
Parameters 29 & 39 respectively and follow the exact same steps
as for Channel 1.
19P
C12320
CALIBRATION MODE
All Calibration and Set-up functions are executed via the keypad in Calibration
Mode. Each function or parameter has a unique code with which to access and
edit values. For a complete listing of all parameters, see Appendix A.
ENTERING INTO CALIBRATION MODE
TO ENTER CALIBRATION MODE FOR SCALE CHANNEL 1:
1. Enter 19 followed by the [PRINT/SELECT] key.
2. The display will flash “ PA55 ”. At this point, a four-digit
password is required.
3. Enter 1111 (factory default password). A blinking “C” should
appear on the left hand side of the display, indicating
Calibration Mode has been entered. (For more information
on passwords, see Security Features - Page 14)
ENTERING COMMANDS IN CALIBRATION MODE
SELECT A PARAMETER
• Calibration & Set-up parameters are selected by entering their unique
numeric code followed by the [PRINT/SELECT] key. This method is
similar to selecting a function in Normal Weighing Mode.
EDIT A PARAMETER
• After a parameter is selected, its current value will be displayed. There is
a 6 second window to edit the parameter. Parameter values are entered
using the numeric keys followed by the [PRINT/SELECT] key.
• In some cases, the [TARE] key must be used to enter a parameter value.
Specific Parameter Descriptions will address the use of the [TARE] key.
