73
TECHNICAL MANUAL
2P
{}ait
76P
readi
F0r data
Fini5h
[]2000
EXAMPLE: RECEIVE CALIBRATION INFORMATION FROM A PC TO THE
M2000 (CONNECTED TO COM2).
1. Connect the M2000 (COM1) to the PC serial port.
2. Open the Terminal Program (HyperTerminal, Terminal, etc.) on the
PC.
3. Set the program’s communication properties to match those of the
M2000 (or vice versa). For most cases: 9600-N-8-1.
4. Enter Calibration Mode on the M2000.
5. Enter Parameter 76. The display will prompt, “Ready”.
6. Press [2] followed by [PRINT/SELECT] to transmit to COM2.
7. The M2000 will wait to receive the transmission.
8. In Hyper Terminal, go the “TRANSFER” menu and select “SEND
TEXT FILE”.
9. Select the file to send to the M2000. Click “OPEN” when ready.
10. The sent file will appear on the Hyper Terminal screen.
11. The M2000 will display “Finish” when the transfer is complete and
automatically restart.
To transfer Ticket Buffer Information, follow the same steps,
replacing Parameter 76 with Parameter 78 – Capture Ticket Buffer
Information from PC.
