WTI TSM Series User Manual

Apx-4
Appendices
B.2. TSM and RSM-8R8 Series RJ45 Serial Ports
When connecting Devices to TSM Series or RSM-8R8 Series RJ45 Serial Console Ports,
please refer to Figure B.1 and the table below:
Target Device End Adapter Cable WTI Device End
RJSerialConsolePorts:
Cisco Routers, Juniper Routers
and Other Network Devices
with RJ45 Serial Console Port
(None Required) RJ45 Rollover Cable:
RJ-ROLL (7 Feet)
RJ-ROLL-25 (25 Feet)
WTI TSM Series
and RSM-8R8
Series RJ45, DCE
Serial Console Port
DB9MSerialConsolePorts:
Linux PC or Liinux Laptop, WTI
RSM Series Units,
WTI MPC SEries Units and
Other Devices with a DB9M
Serial Console Port
DX9F-DTE-RJ
Snap Adapter
RJ45 Straight Cable:
RJX-7 (7 Feet)
RJX-15 (15 Feet)
RJX-25 (25 Feet)
RJX-50 (50 Feet)
DB25FSerialConsolePorts:
Terminal/DTE and Other
Devices with DB25F Serial
Console Port
DX25M-DTE-RJ
Snap Adapter
RJ45 Straight Cable:
RJX-7 (7 Feet)
RJX-15 (15 Feet)
RJX-25 (25 Feet)
RJX-50 (50 Feet)
Note:ForRJ45consoleportsontargetdevicesthatarenotpinnedasaCisco
interface,trystandardCat5straightcable.Forallothernon-standardinterfaces,
pleasecontactWTITechnicalSupportforassistanceandbepreparedto
provideaserialpinoutandsignaldirectionsforthetargetinterface.
