5-34
Basic Configuration
5.8. Serial Port Configuration
The Serial Port Configuration menus allow you to select parameters for the TSM/RSM's
Serial Ports as well as the Internal Modem Port.
The Serial Ports can be configured for connection to a local PC or Modem. In addition,
the Serial Port Configuration menu can also be used to set communications parameters,
disable Administrator level commands and also select a number of other Serial Port
Parameters described in Section 5.8.2.
When responding to prompts, invoking commands, and selecting items from port
configuration menus, note the following:
• Configuration menus are only available to Administrator level accounts.
• If you are configuring the TSM/RSM via modem, modem parameters will not be
changed until after you exit command mode and disconnect from the unit.
• On TSM-8 Series, RSM-8 Series and RSM-8R8 Series units, Port 9 is the optional
Internal Modem Port.
• On RSM-16 Series units, Port 17 is the optional Internal Modem Port.
• On TSM-24 Series units, Port 25 is the optional Internal Modem Port.
• On TSM-40 Series units, Port 41 is the optional Internal Modem Port.
• The Modem Port is not present on TSM models that end with the "NMI" suffix.
