168
Chapter 5 EDIT Mode
TRIM/LOOP Function
TRIM/LOOP - WvMode (Set Wave Mode)
Sets the loop mode and the start-address velocity sensitivity.
PROGRAM
TRIM / LOOP
RECORD
PROGRAM
TOTAL EQ
PLAY
EDIT
REC
DISK
UTILITY
SAMPLE
MAP / OUT
SETUP
SAMPLE
PANEL PLAY
EASY EDIT
FILTER
METER
SEQUENCE
SEQUENCE
EFFECT
EG
EFFECT
VOLUME
MASTER
SETUP
LFO
EXT CTRL
DISK
SYSTEM
CONTROL
MIDI / CTRL
MONITOR
IMPORT
MIDI
Turn Knob 1 to select WvMode.
Knob 1 Knob 2 Knob 3 Knob 4 Knob 5
Turn action ✔✔✔ --
Push action ✔ ----
• Use this page to select the loop mode and the start-address velocity sensitivity.
• The right side of the screen indicates the selected sample’s sampling rate.
Knob 1 Change Page Select P/S
• Turn the knob to change to a different page within the TRIM/LOOP function. Avail-
able pages are: Config, Wave, Loop, and WvMode (this page).
• Push the knob to move to the Program/Sample Selection screen. (☞95)
Knob 2 LpMode = Select from 6 types.
• Sets the loop mode. (Note the you can also use this setting to cause the sample to
play back in reverse.)
• The six loop modes are illustrated and described on the next page.
Knob 3 Vel → Start = -63,...,+63
This value sets the start-address velocity sensitivity: the degree by which the start point
varies in response to the velocity (force) of the played note. This feature gives you added
control over the attack part of the playback.
A value of 0 leaves the start address constant for all velocities. Positive values cause the
start-point to move forward (the address to get higher) at higher velocities, and to move
backward at lower velocities. Negative settings have the opposite effect.
To Next Page
