Yamaha A3000 User Manual

289
Chapter 8 UTILITY Mode
Chapter 8
TOTAL EQ Function
TOTAL EQ - Freq
Sets the equalizer frequency points.
PROGRAM
TRIM / LOOP
RECORD
PROGRAM
TOTAL EQ
PLAY
EDIT
REC
DISK
UTILITY
SAMPLE
MAP / OUT
SETUP
SAMPLE
PANEL PLAY
EASY EDIT
FILTER
METER
SEQUENCE
SEQUENCE
EFFECT
EG
EFFECT
VOLUME
MASTER
SETUP
LFO
EXT CTRL
DISK
SYSTEM
CONTROL
MIDI / CTRL
MONITOR
IMPORT
MIDI
Turn Knob 1 to select Freq.
Knob 1 Knob 2 Knob 3 Knob 4 Knob 5
Turn action ✔✔✔✔✔
Push action ✔ ----
Use this page to set the equalizer’s four frequency points.
Knob 1 Change Page Select P/S
• Turn the knob to change to a different page within the TOTAL EQ function. Available
pages are: Gain, Freq (this page), and Width.
• Push the knob to move to the Program/Sample Selection screen. (☞95)
Knob 2 LowBoost = 32Hz,...,2.0kHz
Sets the low-boost frequency point.
Knob 3 Low = 32Hz,...,2.0kHz
Sets the frequency point for the low-frequency band.
Knob 4 Middle = 32Hz,...,16.0kHz
Sets the frequency point for the mid-frequency band.
Knob 5 High = -500Hz,...,16.0kHz
Sets the frequency point for the high-frequency band.

Yamaha A3000 Specifications

General

Sampling Rate	44.1kHz
MIDI	In/Out/Thru
Type	Sampler
Effects	Reverb, Chorus, Delay
Display	LCD
Storage	Floppy disk drive
