164
Chapter 5 EDIT Mode
TRIM/LOOP Function
TRIM/LOOP - Wave (Edit Waveform)
Sets start and end addresses, and “trims” the waveform.
PROGRAM
TRIM / LOOP
RECORD
PROGRAM
TOTAL EQ
PLAY
EDIT
REC
DISK
UTILITY
SAMPLE
MAP / OUT
SETUP
SAMPLE
PANEL PLAY
EASY EDIT
FILTER
METER
SEQUENCE
SEQUENCE
EFFECT
EG
EFFECT
VOLUME
MASTER
SETUP
LFO
EXT CTRL
DISK
SYSTEM
CONTROL
MIDI / CTRL
MONITOR
IMPORT
MIDI
Turn Knob 1 to select Wave.
Knob 1 Knob 2 Knob 3 Knob 4 Knob 5
Turn action ✔✔✔✔ -
Push action ✔✔✔✔✔
Use this page to select the playback start and end points on the waveform. You can also
use it to delete the unused area at each end of the waveform so as to free up additional
memory.
FYI
You can use the EndType setting on the Configure page to select the method for display-
ing the end address. (☞161)
Knob 1 Change Page Select P/S
• Turn the knob to change to a different page within the TRIM/LOOP function. Avail-
able pages are: Config, Wave (this page), Loop, and WvMode.
• Push the knob to move to the Program/Sample Selection screen. (☞95)
Knob 2 Start = 0, ...,
end address
Realtime Set
• Sets the playback “start” address on the waveform. (Note that the waveform itself
always starts at address 0.) The concept is illustrated below.
• Note that the actual playback start location is also determined by the settings that
you make at the Wave Mode page (☞168).
Start Address
Playback Area of Waveform
End Address
• If you push this knob while playing the sample with the AUDITION key or an external
keyboard, the start address automatically resets to the current playback location.
To Next Page
