Panel and Connector Arrangement
8
MASTER VOL REC VOL
PHONES L INPUT R
1 2 3 4 5
(5)(2)
(1)
(3)
(4)
(7)(6)
Panel and Connector Arrangement
Front Panel (Left Side)
(1) MASTER VOL (Master Volume)
Adjusts the output level at the STEREO OUT connectors only. This knob does not affect
the output level at the ASSIGNABLE OUT connectors, or at the various connectors
provided on the optional I/O expansion board (AIEB1 board).
