298
Chapter 8 UTILITY Mode
MASTER Function
MASTER Function
Use this function to adjust the system’s output pitch, to adjust the level to the stereo
outputs, and to set an assignable-output destination for the stereo output signal.
MASTER - Tuning
Sets the system-wide tuning.
PROGRAM
TRIM / LOOP
RECORD
PROGRAM
TOTAL EQ
PLAY
EDIT
REC
DISK
UTILITY
SAMPLE
MAP / OUT
SETUP
SAMPLE
PANEL PLAY
EASY EDIT
FILTER
METER
SEQUENCE
SEQUENCE
EFFECT
EG
EFFECT
VOLUME
MASTER
SETUP
LFO
EXT CTRL
DISK
SYSTEM
CONTROL
MIDI / CTRL
MONITOR
IMPORT
MIDI
Turn Knob 1 to select Tuning.
Knob 1 Knob 2 Knob 3 Knob 4 Knob 5
Turn action ✔✔✔ --
Push action ✔ ----
Use this page to adjust the tuning (shift the pitch) of all system output.
The lower right of the screen indicates the degree of pitch shift, with respect to note A3.
The value to the left of the arrow indicates the normal frequency for A3 (which is 440Hz),
while the value to the right indicates the “tuned” frequency.
Knob 1 Change Page Select P/S
• Turn the knob to switch between the function’s Tuning and StOut pages.
• Push the knob to move to the Program/Sample Selection screen. (☞95)
Knob 2 Coarse = -127,...,+127
Turn the knob to adjust the tuning, in semitone increments.
Knob 3 Fine = -63,...,+63
Turn the knob to adjust the tuning in increments of 1.171875 cent.
(Note: 100␣ cents = 1 semitone)
