Yamaha A3000 - TOTAL EQ Function

287
Chapter 8 UTILITY Mode
Chapter 8
TOTAL EQ Function
TOTAL EQ Function
This function sets up the 4-band equalizer applied to the stereo-output signal.
You set up the equalizer by setting its gain, frequency, and width parameters. The fol-
lowing illustration shows how these parameters operate on the output frequency.
Level
Low
Width
LowBoost
Gain
Low
Freq
Middle
Freq
High
Freq
Middle
Width
High
Width
Frequency
LowBoost
Freq
Low
Gain
High
Gain
Middle
Gain
Important
The 4-band equalizer does not operate on assignable output. If you choose to branch the
stereo-output signal to a designated assignable-output pair, however (To AsgnOut pa-
rameter;☞299), then equalization will apply to the output at both locations.
FYI
The equalization you set here applies to all sound directed to the stereo output. If you
have set the A3000 up temporarily in a studio or sound stage, the equalizer offers a
convenient way to make final adjustments to match the acoustics of your environment.
