181
Chapter 5 EDIT Mode
Chapter 5
MAP/OUT Function
Knob 1 Change Page Select P/S
• Turn the knob to change to a different page within the MAP/OUT function. Available
pages are: KeyRnge, VelRnge, Lvl&Mode, Output, Pitch, Expand, and LvlScale (this
page).
• Push the knob to move to the Program/Sample Selection screen. (☞95)
Knob 2 Level1 = 0,...,127
Sets the Level1 output level. (See illustration on preceding page.)
Knob 3 BP1 = C-2,...,( BP2 - 1 semitone ) MIDI IN
• Selects Breakpoint 1.
• Push the knob if you want to set the value using an external MIDI device. The knob
indicator begins blinking, indicating that the A3000 is ready to receive MIDI input.
Transmit the appropriate note value, then lock the setting in by pressing the knob
again (or else press a different MIDI IN knob, or change to a different screen).
Knob 4 BP2 = ( C-2 + 1 semitone ),...,G8 MIDI IN
• Selects Breakpoint 2.
• Push the knob if you want to set the value using an external MIDI device. (See expla-
nation directly above.)
Knob 5 Level2 = 0,...,127
Sets the Level2 output level.
