204
Chapter 5 EDIT Mode
LFO Function
Knob 2 Wave = Saw, Triangl, Square, S/H
This parameter selects the LFO waveform. The waveform, in turn, determines the type
of modulation (oscillation) applied to the sample’s filter, pitch, and amplitude.
Modulation
Saw (Sawtooth wave)
Time
Modulation
Triangl (Triangle wave)
Time
Modulation
Square
Time
Modulation
S/H (“Sample & hold”: random pattern)
Time
Knob 3 Speed = 0,...,127
• This value sets the modulation speed for the saw, triangle, or square waveform. Higher
values produce faster modulation.
• Modulation speed for the S/H waveform must be set at the program side (☞128). If
you have selected the S/H waveform, the screen displays the current program-side
setting. You cannot change the setting from this page.
Knob 4 Delay = 0,...,127
This parameter sets the interval between Note On and the onset of LFO modulation.
Higher values produce longer delay together with a more gradual buildup of the modu-
lation level.
Knob 5 Sync = off, on
This setting selects whether LFO oscillation always begins from the same phase (at the
same point in the LFO waveform).
If you set the value to on, LFO oscillation will restart from phase 0 (the leftmost point in
the above illustrations) with each new note that you play.
