Yamaha A3000 - Connecting Audio Inputs

Connecting the A3000 Outputs
23
Chapter 1 Setting Up
Chapter 1
For stereo output:
STEREO OUT
R L/MONO
ASSIGNABLE OUT
RL
A3000 Rear Panel Amp, mixer, etc.
L
INPUT
R
For assignable output:
STEREO OUT
R L/MONO
ASSIGNABLE OUT
RL
A3000 Rear Panel Amp, mixer, etc.
L
INPUT 1
R L
INPUT 2
R
Assignable output using AIEB1 expansion board:
STEREO OUT
ASSIGNABLE OUT
R L/MONO
123456
ASSIGNABLE OUT
RL
A3000
Rear Panel
Amp, mixer, etc.
L
INPUT 1
R L
INPUT 2
INPUT 3 INPUT 4 INPUT 5
R
LRLRLR
(It is not necessary, of course, to connect up all of the outputs on the expansion board.
Connect only the outputs you need to use.)
