LOWER UNIT (F15A/F9.9C)
LOWR
EXPLODED DIAGRAM
6-2
REMOVAL AND INSTALLATION CHART
Step
12
13
14
15
16
17
18
Q’ty
1
1
2
1
1
1
1
Service points
Reverse the removal steps for installation.
Procedure/Part name
Screw
Nut
Water inlet grill
Bolt
Toothed washer
Anode
Trim tab (for S-transom models)
