DRIVE SHAFT, FORWARD GEAR, SHIFT ROD AND
OIL SEAL HOUSING (F15A/F9.9C)
LOWR
DRIVE SHAFT, FORWARD GEAR, SHIFT ROD AND OIL SEAL HOUSING (F15A/F9.9C)
EXPLODED DIAGRAM
6-13
REMOVAL AND INSTALLATION CHART
Step
1
2
3
4
5
6
7
Q’ty
1
1
1
1
*
1
1
Service points
Follow the left ”Step” for removal.
Procedure/Part name
DRIVE SHAFT, FORWARD GEAR AND
SHAFT ROD REMOVAL
Propeller shaft ass’y
Water pump
Pinion gear nut
Pinion gear
Plate washer
Thrust bearing
Pinion gear shim
Drive shaft
Forward gear ass’y
(along with the tapered roller bearing)
*: as required
To Next Page
