BOTTOM COWLING ASS’Y (F15A/F9.9C)
BRKT
EXPLODED DIAGRAM
9
0
D
C
A
8
2
1
D
E
H
I
J
F
G
M
L
K
D
E
6
7
3
4
5
7-12
REMOVAL AND INSTALLATION CHART
Step
1
2
3
4
5
6
7
8
9
0
q
Q’ty
3
1
2
1
1
2
1
1
4
1
1
Service points
Follow the left ”Step” for disassembly.
M6 x 30 mm
M6 x 20 mm
M6 x 25 mm
Procedure/Part name
BOTTOM COWLING ASS’Y DISASSEMBLY
Bolt
Fitting plate
Fuel hose
Fuel joint
Battery cable (for EH/E models)
Bolt
Neutral switch ass’y (for EH models)
Clip
Bolt
Shift rod lever
Shift rod ass’y
