Yamaha F15A - Page 406

E
BOTTOM COWLING ASS’Y (F15A/F9.9C)
BRKT
7-13
EXPLODE DIAGRAM
9
0
D
C
A
8
2
1
D
E
H
I
J
F
G
M
L
K
D
E
6
7
3
4
5
REMOVAL AND INSTALLATION CHART
Step
w
e
r
t
y
u
i
o
p
a
s
d
Q’ty
1
1
2
2
1
1
1
1
1
1
1
1
Service points
M6 x 20 mm
M6 x 12 mm
Reverse the disassembly steps for assembly.
Procedure/Part name
Bolt
Spring
Bolt
Bracket 1
Bolt
Bracket 2
Bolt
Plate
Collar
Cowling lock lever ass’y
Washer
Collar
