C. Using upper turret and HD2 for turning, lower turret and HD1 is using for milling
1. Sample program
G109L1
M902
M302
G00G18G90G95G54G96
G40G49G80G67G69
G91G28X0
G28Z0
G28Y0
G28B0
M950
T001T002M06
G91G28X0
G28Y0
G28Z0
M108
G90G53B90.
M107
G92S1500R2
G96M303S80R2
G10.9X1
M08
M951
G90G43G0X-300.0Y0Z-30.0 H1P1
M250
Z0
G1X-350.F0.3.
G0Z30.
G40
M305
M952
M09
G91G28X0
G28Z0
G28Y0
G28B0
M30
Machining
(Upper turret: HD2- Turning, Lower turret: HD1- Milling (1/2))
jiku
Preparation motion for machining
 G109L1: Upper turret selection
 M902: HD2 spindle selection
 M302: C-axis disconnect / turning mode
 G95: Feed per revolution
 G96: Constant surface speed control ON
 T001M06: Tool change (TNo.01)
 B-axis positioning
 M107: B-axis clamping
 G92S1500: Spindle speed range setting
 G96S80: Surface speed 80 m/min
 R2: Set the HD2
 M303: Turning spindle2 forward rotation
 G10.9X1: Diameter data input mode
 M08: Flood coolant ON
Machining motion
End motion for machining
 M305: Turning spindle2 Rotation stop
 M09: All coolants OFF
 Each axis positioning to zero return
 M30: Reset and rewind
