SUPPLEMENT 5
5-55
No.
Item
Type A
F34 bit4 = 0
Type B
F34 bit4 = 1
7
Command for inclined-plane machining with macro interruption being
active
Impossible
Possible
8
MDI interruption
Impossible
Possible
9
Use of corner chamfering/rounding command
Impossible
Possible
10
Use of G68.2 or G53.1 in a subprogram of the nesting level 8
Possible
Impossible
11
Restart operation from a block in the mode of inclined-plane machining
(or from a G69 block)
Possible
Impossible
12
Programming format (using Eulerian angles)
Possible
Possible
13
Programming format (using roll, pitch, and yaw angles, three points in
the plane, two vectors, projection angles, or tool-axis direction)
Possible
Impossible
Tool radius compensation (for five-axis machining as well), fixed cycle, and tool tip
point control must be selected and cancelled within the mode of inclined-plane
machining.
Positioning commands (under G0) in the mode of inclined-plane machining are always
executed in interpolation-type paths.
Since the feature coordinate system will be established on the basis of the workpiece
coordinate system (which is independent of the positions of table rotation), do not fail
to set the table to the required angular position before selecting the mode of
inclined-plane machining.
Reference angular position for defining a feature coordinate system.
Use parameter F144 bit 1 to select the reference angular position for setting the angle
of rotation in a command (with G68.2) for the definition of a feature coordinate system.
Reference
position
Current angular position of the table
F144 bit 1 = 0
0° position of the table
F144 bit 1 = 1
Description
A feature coordinate system is
established with reference to the current
position of the table on the rotational
axis concerned.
A feature coordinate system is established
with reference to the 0° position of the table
on the rotational axis concerned.
Remarks
Do not fail to set the table to the angular
position appropriate for programming
before selecting the mode of
inclined-plane machining.
The feature coordinate system can be defined
with reference to the 0° position of the table,
irrespective of its current position.
Note: The parameter in question (F144 bit1) only applies to G68.2 (out of all relation to
G68.3).
See F. Combination of inclined-plane machining (G68.2, G68.3) [Type A] and other
function in 5-3 Restriction of Combination.
Serial No. 294060
Copyright (c) 2013 YAMAZAKI MAZAK CORPORATION. All rights reserved.
