YAMAZAKI MAZAK VORTEX i Series User Manual

5 SUPPLEMENT
5-80
Function
Code
G43.4 (G43.5)
commanded in
leftward code mode
Leftward code
commanded in G43.4
(G43.5) mode.
Cutting mode
G64


Single user macro call
G65
-

3-D coordinate conversion ON
G68
-
-
3-D coordinate conversion OFF
G69

-
Inclined-plane machining ON
G68.2

-
Inclined-plane machining (by specifying tool-axis
direction) ON
G68.3

-
Inclined-plane machining OFF
G69

-
Finishing cycle
G270
-
-
Longitudinal roughing cycle
G271
-
-
Transverse roughing cycle
G272
-
-
Compound thread-cutting cycle
G276
-
-
Fixed cycle OFF
G80

-
Face driling cycle
G283
-
-
Face tapping cycle
G284
-
-
Face boring cycle
G285
-
-
Fixed cycle A (Longitudinal turning cycle)
G290
-
-
Threading cycle
G292
-
-
Fixed cycle B (Transverse turning cycle)
G294
-
-
Fixed cycle (Chamfering cutter 1, CW)
G71.1
-
-
Fixed cycle (Chamfering cutter 2, CCW)
G72.1
-
-
Fixed cycle (High-speed deep-hole drilling)
G73
-
-
Fixed cycle (Reverse tapping)
G74
-
-
Fixed cycle (Boring 1)
G75
-
-
Fixed cycle (Back spot facing)
G77
-
-
Fixed cycle (Spot drilling)
G81
-
-
Fixed cycle (Tapping)
G84
-
-
Fixed cycle (Reaming)
G85
-
-
Fixed cycle (Back boring)
G87
-
-
Absolute data input
G90


Incremental data input
G91


Inverse time feed
G93


Constant surface speed control ON
G96
-
-
Constant surface speed control OFF
G97

-
Feed per minute (asynchronous)
G94


Feed per revolution (synchronous)
G95
-
-
Subprogram call
G98

-
Return to main program
G99

-
Polar coordinate input ON
G16
-
-
Polar coordinate input OFF
G15

-
Selection between diameter and radius data input
Diameter data input mode OFF
G10.9 X0

-
Selection between diameter and radius data input
Diameter data input mode ON
G10.9 X1
-
-
Serial No. 294060
Copyright (c) 2013 YAMAZAKI MAZAK CORPORATION. All rights reserved.
Serial No. 294060
