2 MACHINE INFORMATION
2-18
7. INTEGREX i-V
[min
-1
]
Machine specification
Turning spindle
Mill Spindle
(12000min
-1
)
Standard
Mill Spindle
High torque
specification
Option
Mill Spindle
High-speed spindle
specification
Option
i-500V/5
2-pallet
35 to 1000
35 to 12000
-
-
i-630V/6
Single
2 to 550
25 to 10000
25 to 5000
25 to 15000
2-pallet
Remark: 3000 min
-1
is upper limit value during tapping cycle.
* Limitations on the rotation of the turning spindle will vary with pallet specifications.
8. INTEGREX e-V
[min
-1
]
Machine specification
Turning
spindle
Standard
Turning
spindle
Option
Mill Spindle
(10000min
-1
)
Standard
Mill Spindle
High torque
specification
Option
Mill Spindle
High-speed
spindle
specification
Option
e-1060V
-
5 to 600
3 to 300
25 to 10000
25 to 5000
-
e-1250V/8
Single
1.8 to 500
1.1 to 300
2-pallet
e-1550V
-
3 to 300
-
e-1600V/10
Single
5 to 300
25 to 15000
2-pallet
e-1850V
-
5 to 250
5 to 150
-
Remark : 3000 min
-1
is upper limit value during tapping cycle.
9. VORTEX i-V
[min
-1
]
Machine specification
Mill Spindle
(10000min
-1
)
Standard
Mill Spindle
High torque specification
Option
Mill Spindle
High-speed spindle
specification
Option
i-630V/6
Single
25 to 10000
25 to 5000
25 to 15000
2-pallet
i-800V/8
Single
2-pallet
Remark: 3000 min
-1
is upper limit value during tapping cycle.
