MACHINING PROGRAM 4
4-35
A. Sample program
G109L1
M901
M200
M212
G0G90G94G55G97
G40G49G80G67G69
G91G28X0
G28Z0
G28Y0
T001T00M06
G91G28X0
G28Y0
G28Z0
M108
G90G53B40.0
G97S12000M03
G10.9X0
M51
G61.1
M108
G17
G90G53B40.
G90G00C0.
G90G43G00X58.03Y9.992Z131.564B40.C0.H1P1
M107
G05P2
X33.9245Z102.8365
G01X33.5319Y0.F250.
X33.5672Z102.6365C-4.5
(Machining contour)
X36.7457Y-9.9923
G00X58.03Z112.2021
G05P0
G64
M05
M09
G91G28X0
G28Z0
G28Y0
M108
G90G53B0
M30
Machining contour
Preparation motion for machining
 G109L1: Upper turret selection
 M901: HD1 spindle selection
 M200: C-axis connect/Milling mode select
 M212: C-axis unclamping
 G94: Feed per minute
 G97: Constant surface speed control OFF
 T001M06: Tool change (TNo.01)
 B-axis positioning
 G97S12000: Rotation speed 12000 min
-1
 M03: Forward milling spindle rotation
 G10.9X0: Radius data input mode
 M51: Milling spindle-through coolant ON
Machining motion
 G61.1:
Geometry compensation
 Rotational axis positioning
 G43H**P1: Tool length offset
 M107: B-axis clamp
 G5P2: High-speed
machining mode ON
 (Machining pattern)
 G5P0: High-speed
machining mode OFF
 G64:
Geometry compensation OFF
End motion for machining
 M05: Stop of milling spindle rotation
 M09: coolants OFF
 Each axis positioning to zero return
 M30: Reset and rewind
(4-axis machining)
