4 MACHINING PROGRAM
4-40
C. Parameter setting
The main parameter of processing is described.
The table shows the standard parameter and setting set in this manual.
Parameter setting
High-speed smoothing control valid
(No deceleration at very slightly stepped sections)
Type of coordinate system for controlling the tool tip point
The table coordinate system
Tool tip point control scheme Joint interpolation
Override scheme for G0
The clamping speed at the machine control point
Override scheme for G1
The clamping speed at the machine control point
C-axis reference position 0 degrees
Rotational axis shape correction Valid
The axis does not move when command G49 is issued
During independent start of tool tip point control No movement
Note 1: High-speed smoothing control function is valid during high-speed mode with the shape
correction being selected.
Some of the outstanding features of high-speed smoothing control are listed below.
Effective for machining a die of a smooth shape using a microsegment program.
Speed control is insusceptible to the effects of any errors contained in the tool path.
If adjacent paths are similar in terms of geometrical accuracy, acceleration and
deceleration patterns will also be similar.
Even at the sections where corner deceleration is not necessary with respect to the
angle, speed will be clamped if the estimated acceleration is great.
