YASKAWA SGDM Series User Manual

4 SERVOPACK Specifications and Dimensional Drawings
4-16
4.6 SERVOPACK Dimensional Drawings
SERVOPACK dimensional drawings are grouped according to the mounting method and the capacity.
(1) Base-mounted Type
(2) Rack-mounted Type
(3) Duct-ventilated Type
Supply Voltage
SERVOPACK
Reference
Capacity Model SGDM-D/DA
Single-phase
100 V 30 W / 50 W / 100 W A3B / A5B / 01B
4.7.1
200 V 30 W / 50 W / 100 W / 200 W A3A / A5A / 01A / 02A
100 V 200 W 02B
4.7.2
200 V 400 W 04A
Three-phase
200 V 500 W / 800 W / 1.0 kW 05A / 08A / 10A
4.7.3
200 V 1.5 kW 15A
4.7.4
200 V 2.0 kW / 3.0 kW 20A / 30A
4.7.5
200 V 5.0 kW 50A
4.7.6
200 V 6.0 kW / 7.5 kW 60A / 75A
4.7.8
200 V 11.0 kW / 15.0 kW 1AA / 1EA
4.7.8
Supply Voltage
SERVOPACK
Reference
Capacity Model SGDM-D/DA-R
Single-phase
100 V 30 W / 50 W / 100 W A3B / A5B / 01B
4.8.1
200 V 30 W / 50 W / 100 W / 200 W A3A / A5A / 01A / 02A
100 V 200 W 02B
4.8.2
200 V 400 W 04A
Three-phase
200 V 500 W / 800 W / 1.0 kW 05A / 08A / 10A
4.8.3
200 V 1.5 kW 15A
4.8.4
200 V 2.0 kW / 3.0 kW 20A / 30A
4.8.5
200 V 5.0 kW 50A
4.8.6
Supply Voltage
SERVOPACK
Reference
Capacity Model SGDM-D/DA-P
Three-phase
200 V 6.0 kW / 7.5 kW 60A / 75A
4.9.1
200 V 11.0 kW / 15.0 kW 1AA / 1EA
4.9.2
