YASKAWA SGDM Series User Manual

4 SERVOPACK Specifications and Dimensional Drawings
4.7.4 Three-phase 200 V: 1.5 kW (15AD, 15ADA)
4-20
4.7.4 Three-phase 200 V: 1.5 kW (15AD, 15ADA)
-
CN3
CN1
CN2
YASKAWA
YASKAWA
SERVOPACK
SGDM-
5.5 (0.22)
5
(0.20)*
MODE/SET
CHARGE POWER
DATA/
Heat sink
110 (4.33)
160 (6.30)
2×φ5 (φ0.20)
holes
Ground
terminal
2×M4 screws
Terminal
block
5 (0.20)
180 (7.09)
4
(0.16)
Nameplate
75 (2.95)*
160 (6.30)
5
(0.20)*
100±0.5 (3.94±0.02)
110 (4.33)
149.5±0.5 (5.89±0.02)
(Mounting pitch)
(Mounting pitch)
4×M4 screw holes
Mounting Hole Diagram
5*
(0.20)
Cooling fan
* Reference length
Units: mm (in)
Approx. mass: 2.8 kg (6.17 lb)
External Terminal Connector
SERVOPACK Connector
Connector
Symbol
SERVOPACK
Connector Model
Manufacturer
CN1 10250-52A2JL Sumitomo 3M Co., Ltd.
CN2 53460-0611 Molex Japan Co., Ltd.
CN3 10214-52A2JL Sumitomo 3M Co., Ltd.
L1C L2CL2 L3L1
Three-phase
200 VAC
50/60 Hz
Single-phase
200 VAC
50/60 Hz
Main circuit
power supply
Control power
supply
