YASKAWA SGDM Series User Manual

4 SERVOPACK Specifications and Dimensional Drawings
4.7.6 Three-phase 200 V: 5.0 kW (50ADA)
4-22
4.7.6 Three-phase 200 V: 5.0 kW (50ADA)
Ve r.
SGDM-50ADA
83 (3.27)*
CN2
CN3
4-pin terminal
M4 screw
250 (9.84)
Heat sink 6-pin terminal
M5 screw
75 (2.95)*
230 (9.06)
1.6
(0.06)
125 (4.92)
6 (0.24)
238.5 (9.39)
5.7
(0.22)
5.5 (0.22)
5*
(0.20)
5 (0.20)*
3-pin terminal
M5
screw
135 (5.31)
CN1
(100°)
YASKAWA SERVOPACK
L1
L2
L2C
B1
B2
B3
U
V
W
L1C
L3
1
+
2
+
-
250 (9.84)
238.5±0.5 (9.39±0.02)
125±0.5
(4.92±0.02)
5.5 (0.22)*
5*
(0.20)
5 (0.20)*
6 (0.24)
MODE/SET
CHARGE POWER
DATA/
Nameplate
(Mounting pitch)
(Mounting pitch)
4×M5 screw taps
Mounting Hole Diagram
* Reference length
Units: mm (in)
Approx. mass: 5.5 kg (12.13 lb)
Ground terminal
M5 screw
External Terminal Connector
SERVOPACK Connector
Connector
Symbol
SERVOPACK
Connector Model
Manufacturer
CN1 10250-52A2JL Sumitomo 3M Co., Ltd.
CN2 53460-0611 Molex Japan Co., Ltd.
CN3 10214-52A2JL Sumitomo 3M Co., Ltd.
L1C L2CL2 L3L1
200 VAC
50/60 Hz
Three-phase
200 VAC
50/60 Hz
Single-phase
Main circuit
power supply
Control power
supply
