2.6 Selecting Peripheral Devices
2-33
2
The SGDM SERVOPACK does not include a protective grounding circuit. Install a ground-fault protector to
protect the system against overload and short-circuit or protective grounding combined with the molded-case
circuit breaker.
2.6.3 Noise Filters, Magnetic Conductors, Surge Suppressors and DC Reactors
Note: 1. If some SERVOPACKs are wired at the same time, select the proper magnetic contactors according to the
total capacity.
2. The following table shows the manufacturers of each device.
IMPORTANT
Main Circuit
Power
Supply
SERVOPACK Model
Recommended Noise Filter
(Refer to 5.8.10.)
Magnetic
Contactor
(Refer to
5.8.11.)
Surge
Suppressor
(Refer to
5.8.12.)
DC
Reactor
(Refer to
5.8.13.)
Capacity
(kW)
SGDM
-
Type Specifications
Single-phase
100 V
0.03 A3BD, A3BDA
FN2070-6/07
Single-phase
250 VAC, 6 A
HI-11J (20 A) TU-25C120
0.05 A5BD, A5BDA
0.10 01BD, 01BDA X5063
0.20 02BD, 02BDA FN2070-10/07
Single-phase
250 VAC, 10 A
X5062
Single-phase
200 V
0.03 A3AD, A3ADA
FN2070-6/07
Single-phase
250 VAC, 6 A
HI-11J (20 A) TU-25C240
0.05 A5AD, A5ADA
0.10 01AD, 01ADA X5071
0.20 02AD, 02ADA X5070
0.40 04AD, 04ADA FN2070-10/07
Single-phase
250 VAC, 10 A
X5069
Three-phase
200 V
0.45 05AD, 05ADA FN258L-7/07
Three-phase
480 VAC, 7 A
HI-11J (20 A)
TU-25C240
X5061
0.75 08AD, 08ADA
FN258L-16/07
Three-phase
480 VAC, 16 A
HI-15J (35 A)
1.0 10AD, 10ADA
1.5 15AD, 15ADA
X5060
2.0 20AD, 20ADA
HI-20J (35 A)
3.0 30AD, 30ADA FN258L-30/07
Three-phase
480 VAC, 30 A
X5059
5.0 50ADA
FMAC-0934-5010
Three-phase
440 VAC, 50 A
HI-25J (50 A)
TU-65C240
X5068
6.0 60ADA
7.5 75ADA FMAC-0953-6410
Three-phase
440 VAC, 64 A
HI-35J (65 A)
11.0 1AADA
FS5559-150-35
Three-phase
480 VAC, 150 A
HI-50J (75 A)
15.0 1EADA
HI-65J (100 A)
Peripheral Device Manufacturer
Noise Filter
FN, FS type: Schaffner Electronic
FMAC type: Timonta AG
Magnetic Contactor Yaskawa Controls Co., Ltd.
Surge Suppressor Yaskawa Controls Co., Ltd.
DC Reactor Yaskawa Controls Co., Ltd.
