2.4 Σ

II Series SERVOPACKs and Applicable Servomotors

2-17

2.4.2 SGDM SERVOPACKs and SGMCS Servomotors

The SGMCS SERVOPACK can be combined only with a SGDM SERVOPACK with software version 32 or

later.

Note that SGMCS SERVOPACK can’t be used with the SGDM-D and SGDM SERVOPACK with soft-

ware version 32 or earlier.

Σ-II Series SGMCS Servomotor

Σ-II Series SGDM SERVOPACK

Single-phase 200 VAC Three-phase 200 VAC

SGMCS

(Direct-drive series)

150min

-1

8 models

200min

-1

9 models

02B

02ADA −

05B

02ADA −

07B

02ADA −

04C

04ADA −

10C

04ADA −

14C

04ADA −

08D

04ADA −

17D

04ADA −

25D

04ADA −

16E

− 08ADA

35E

− 08ADA

45M

− 10ADA

80M

− 15ADA

1AM

− 20ADA

80N

− 15ADA

1EN

− 30ADA

2ZN

− 30ADA
