YASKAWA SGDM Series User Manual

4 SERVOPACK Specifications and Dimensional Drawings
4.9.2 Three-phase 200 V: 11.0 kW/15.0 kW (1AADA-P/1EADA-P)
4-32
4.9.2 Three-phase 200 V: 11.0 kW/15.0 kW (1AADA-P/1EADA-P)
17 (0.67)
34
(1.34)
126
(4.96)
122 (4.80)
282 (11.10)
Regenerative
resistor/
control circuit
terminal
Main circuit
terminal
10 (0.39)
18.5 (0.73)
413 (16.26)
18.5 (0.73)
20 (0.79)
99 (3.90)
132 (5.20)
146 (5.75)
9 (0.35)
11 (0.43)*
7.5 (0.30)
435 (17.13)
415 (16.34)
7.5 (0.30)*
4.5
(0.18)
8
(0.31)
235 (9.25)
244 (9.61)
4.5
(0.18)*
8*
(0.31)
CN3
CN8
CN5
SERVOPACK 200V
SGDM-
Ve r.
YASKAWA
CN1 CN2
CHARGE
E
P1 B r t
L1 L2 L3 +1 - U V
140 (5.51)
160 (6.30)
46
(1.81)
27(1.06)
34
(1.34)
45
(1.77)
151 (5.94)
12.5
(0.49)
235 (9.25)
7
(0.28)
12.5 (0.49)*
260 (10.24)
7.5 (0.30)*
7.5 (0.30)*
450 (17.72) 435 (17.13)
Regenerative
Resistor terminal
M6
26.5 (1.04)
320 (12.60)
POWER
MODE/SET
DATA/
BATTERY
Externals
Punched hole
Mounting Hole Diagram
4×M6 screw holes
Cooling fan
Ground
terminal M8
Ground
terminal
Nameplate
Main circuit
terminal M8
Control circuit
terminal M4
A
View A
* Reference length
Units: mm (in)
Approx. mass: 22 kg (48.50 lb)
External Terminal Connector
SERVOPACK Connector
Connector
Symbol
SERVOPACK
Connector Model
Manufacturer
CN1 10250-52A2JL Sumitomo 3M Co., Ltd.
CN2 53460-0611 Molex Japan Co., Ltd.
CN3 10214-52A2JL Sumitomo 3M Co., Ltd.
L1C L2CL2 L3L1
External
regenerative
resistor
B1 B2
200 VAC
50/60 Hz
Three-phase
200 VAC
50/60 Hz
Single-phase
Main circuit
power supply
Control power
supply
