2 Selections
2.6.4 Regenerative Resistors and Brake Power Supply Units
2-34
2.6.4 Regenerative Resistors and Brake Power Supply Units
* 1. For the optional JUSP-RA04 Regenerative Resistor Unit.
* 2. For the optional JUSP-RA05 Regenerative Resistor Unit.
* 3. Be careful when connecting the power supply for 24 VDC brake to the local power supply. The local power
supply cannot apply the overvoltage such as surge to the output side, and the output side may be damaged even
if the voltage is applied. Never fail to use the surge suppressor.
Note: 1. If the SERVOPACK cannot process the regenerative power, an external regenerative resistor is required.
Refer to 5.8.6 External Regenerative Resistor, 5.8.7 Regenerative Resistor Unit, and 6.5 Connecting Regen-
erative Resistors.
2. The following table shows the manufacturers of each device.
Main Circuit
Power Supply
SERVOPACK Model
Regenerative Resistor
(Refer to 5.8.6, 5.8.7, and 6.5.)
Brake Power Supply
Unit
(Refer to 5.8.5.)
Capacity
(kW)
SGDM-
Built-in
Externally
connected
Resistance
(Ω)
Capacity
(W)
Single-phase
100 V
0.03 A3BD, A3BDA
−−
−
24 VDC brake (provided
by a customer)
∗
3
90 VDC brake
• LPDE-1H01
for 100 VAC input
• LPSE-2H01
for 200 VAC input
0.05 A5BD, A5BDA
0.10 01BD, 01BDA
0.20 02BD, 02BDA
Single-phase
200 V
0.03 A3AD, A3ADA
0.05 A5AD, A5ADA
0.10 01AD, 01ADA
0.20 02AD, 02ADA
0.40 04AD, 04ADA
Three-phase
200 V
0.45 05AD, 05ADA
50 60
−
0.75 08AD, 08ADA
1.0 10AD, 10ADA
1.5 15AD, 15ADA 30 70
2.0 20AD, 20ADA 25 140
3.0 30AD, 30ADA 12.5 140
5.0 50ADA 8 280
6.0 60ADA
(6.25
）
∗
1
(880)
∗
1
JUSP-RA04
7.5 75ADA
(3.13)
∗
2
(1760)
∗
2
JUSP-RA0511.0 1AADA
15.0 1EADA
Peripheral Device Manufacturer
External Regenerative Resistor Iwaki Wireless Research Institute
External Regenerative Unit Yaskawa Electric Corporation
Brake Power Supply Unit Yaskawa Controls Co., Ltd.
