10 Upgraded Versions
10.3.5 Automatic Gain Switching Function
10-14
* The factory setting is 1500 for the models with 5 kW or more.
10.3.5 Automatic Gain Switching Function
The automatic gain switching function switches the gain setting between the gain setting 1 and 2 according to the
condition:
Whether position reference is specified or not, or
Position error level, or
AND logic of the above two conditions
The position reference of the automatic gain switching condition indicates the reference pulses from CN1.
Note that the automatic gain switching function is disabled for the control modes other than position control.
And, the real-time autotuning function is disabled while gain setting 2 is selected.
The existing gain switching function by /G-SEL signal is also available. However, it cannot be used with the
automatic gain switching function.
Note that automatic gain switching function is enabled only in position control mode. In the control modes other
than position control, gain setting 1 is used.
When the automatic gain switching is enabled by setting 1 to 3 of Pn10B.2, the gain switching function by /G-
SEL signal is disabled.
Pn409
First Stage Notch Filter Frequency
Setting Range Setting Unit Factory Setting Setting Validation
50 to 2000 1 Hz 2000* Immediately
Pn40A
First Stage Notch Filter Q Value
Setting Range Setting Unit Factory Setting Setting Validation
50 to 400
(0.50 to 4.00)
× 0.01
70
(0.70)
Immediately
Pn40B
Second Stage Notch Filter Frequency
Setting Range Setting Unit Factory Setting Setting Validation
50 to 2000 1 Hz 2000 Immediately
Pn40C
Second Stage Notch Filter Q Value
Setting Range Setting Unit Factory Setting Setting Validation
50 to 400
(0.50 to 4.00)
× 0.01
70
(0.70)
Immediately
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Gain Switching
Gain Setting 1 Gain Setting 2
Pn100: Speed loop gain
Ù
Pn104: Speed loop gain #2
Pn101: Speed loop integral time constant Pn105_Speed loop integral time constant #2
Pn102: Position loop gain Pn106_Position loop gain #2
