4.8 Dimensional Drawings of Rack-mounted SERVOPACK Model
4.8.1 Single-phase 100 V: 30 W/50 W/100 W
(A3BD-R to 01BD-R, A3BDA-R to 01BDA-R)
Single-phase 200 V: 30 W/50 W/100 W/200 W
(A3AD-R to 02AD-R, A3ADA-R to 02ADA-R)
CN3
CN2
CN1
6
(0.24)
YASKAWA SERVOPACK
SGDM-
6 (0.24)
180 (7.09)
160 (6.30)
195 (7.68)
17.5 (0.69)
7.5 (0.30)
17.5 (0.69)
55 (2.17)
10 (0.39)
5 (0.20)
42 (1.65)1.5 (0.06)
22.5 (0.89)
φ
160 (6.30)
130 (5.12)
55 (2.17)
22.5
(0.89)
7.5
(0.30)
180±0.5 (7.09±0.02)
10
(0.39)
2
(0.08)
17 (0.67)
7.5 (0.30)
22.5 (0.89)*
32.5 (1.28)*
5 (φ0.20) hole
24.5 (0.96)
75 (2.95)
7.5 (0.30)*
10 (0.39)
32.5 (1.28)*
Min.166 (6.54)
YASKAWA
CHANGE
L1
C
N
3
L2
L2C
B1
B2
U
V
W
L1C
POWER
+ 1
+ 2
C
N
1
C
N
2
MODE/SET
DATA/
Ground terminal
2×M4 screws
Nameplate
Mounting Hole Diagram
2×M4 screw holes
(Mounting pitch)
* Reference length
Units: mm (in)
Approx. mass: 1.0 kg (2.20 lb)
Terminal
block
External Terminal Connector
SERVOPACK Connector
Connector
Symbol
SERVOPACK
Connector Model
Manufacturer
CN1 10250-52A2JL Sumitomo 3M Co., Ltd.
CN2 53460-0611 Molex Japan Co., Ltd.
CN3 10214-52A2JL Sumitomo 3M Co., Ltd.
L1 L2
Main circuit
power supply
Control power
supply
Single-phase
100/200 VAC
50/60 Hz
L1C L2C
Single-phase
100/200 VAC
50/60 Hz
